Name: Screw Compressor (CSH SeriesCSH6551-50Y)
Brand: Star-Worths Refrigeration Co. Ltd.
SKU: CSH6551-50Y
Availability: InStock

Home Products Bitzer Compressor

Screw Compressor (CSH SeriesCSH6551-50Y)

Product Details:

Place of Origin:	China
Certification:	CE,ROHS,SGS
Model Number:	CSH6551-50Y

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	0
Packaging Details:	Carton
Delivery Time:	7 working Days
Payment Terms:	T
Supply Ability:	1000000PCS/Year

Contact Now

Detailed Product Description

Type:	Screw	Configuration:	Portable
Power Source:	AC Power	Lubrication Style:	Lubricated
Mute:	Yes	Keywords:	Refrigeration Compressor

Screw Compressor (CSH Series)

The CSH series is suitable for universal use and is fitted with connections for economiser and oil cooler. Their integrated oil reservoir and separator system significantly reduces installation time, and permits using the screw compressors in a minimum of space.

Model No.	Condensate Temp.	The Evaporation Temperature(R407C, 50Hz)
Model No.	Condensate Temp.	12.5	10	5	0	-5	-10	-15
CSH6551-50Y	40	163600	149600	124300	102400	83300	66900	52700
CSH6561-60Y	40	201600	184500	153600	126800	103600	83600	66300
CSH7551-70Y	40	235500	215200	178800	147100	119700	95900	75400
CSH7561-80Y	40	277200	253500	210700	173500	141300	113500	89400
CSH7571-90Y	40	312900	286400	238500	196900	160900	129900	103000
CSH8551-110Y	40	392800	359200	298600	245900	200200	160700	126400
CSH8561-125Y	40	451700	413000	343300	282700	230200	184900	145700
CSH8571-140Y	40	512100	468700	390300	322300	263400	212500	168600
CSH9551-180Y	40	674500	616800	512700	422200	343800	275800	217000
CSH9561-210Y	40	781900	715000	594300	489600	398800	320300	252500
CSH9571-240Y	40	883800	808800	673600	556300	454700	366900	291200
CSH9581-280Y	40	1004100	918800	764800	631000	515100	414700	327800
CSH9591-300Y	40	1127200	1032200	860800	712000	583100	471600	375300
